Product Description
AKG-23 Skid Steer
Mini Skid Steer for sale in Toronto, Canada – Heavy Equipment in Toronto (GTA). Looking for mini skid steer to work in residential or commercial units? We sell and deliver all over Canada. Most affordable mini skid steer with Briggs and Stratton engine for sale in Toronto. Gas engine fueled mini skid steer for sale. brand new with warranty and cheap price mini skid steer.
| MINI SKID STEER Parameter Information | ||
| specification | Name | 850 Wheeled |
| Type | Mini Loader, Skid Steer Loader, Skid Loaders | |
| Dimension(Long * width * High) | 1740*900*1370mm | |
| Machine Weight | 860kg | |
| UNIQUE SELLING POINT | EPA Engine | |
| Power | 23hp | |
| Bucket capacity | 0.15m3 | |
| Loading weight | 350kg | |
| Max. loading | 500kg | |
| Operating weight | 870kg | |
| Color | Customer’s Requiement | |
| Hydraulic pressure | 17Mpa | |
| Tire Model | 20*10-10 | |
| Cooling: | Air-Cooled | |
| Electrical voltage | 12V | |
| Battery | 45AH | |
| DIMENSIONS | Overall length with bucket | 2170mm / 85.4 in |
| Length Without Bucket | 1740mm / 68.5 in | |
| Total width | 1150mm / 45.3 in | |
| Max. working height | 2452mm / 96.5 in | |
| Max hinge pin height | 1914mm / 75.3 in | |
| Max. unloading height | 1515mm /59.6 in | |
| Dumping reach | 545mm /21.5 in | |
| Total height of loader | 1370mm / 54 in | |
| Ground clearance | 140mm / 5.5 in | |
| Wheelbase | 657mm / 25.9 in | |
| Angle of departure | 23° | |
| Rollback of bucket on ground | 26° | |
| Dump angle at maximum height | 34° | |
| POWER | Engine maker | Briggs & Stratton |
| Fuel type | Gasoline | |
| Rated power | 17.2kw | |
| Number of cylinder | 3 | |
| Displacement | 625ml | |
| Rated speed | 3600rpm | |
| Max. drive speed | 6km/h | |
| WORKING SYSTEM | Lift time | 4s |
| Tipping Bucket time | 1.3s | |
| Landing time | 3s | |
| Noise Level | 95dB | |
Attachments
