ATLAS ETC-800 Series Flatbed CNC Lathe (Ø800mm swing, 2m~6m B/C)

These Heavy duty horizontal lathes for industrial metal turning applications with with a turning weight of 3000kg Between Center’s and a max Swing over bed of Ø800mm (31″):

• ETC-800×2000 – Ø800x2000mm B/C (31″ x 78″ Inch)
• ETC-800×3000 – Ø800x3000mm B/C (31″ x 118″ Inch)
• ETC-800×4000 – Ø800x4000mm B/C (31″ x 157″ Inch)
• ETC-800×5000 – Ø800x5000mm B/C (31″ x 196″ Inch)
• ETC-800×6000 – Ø800x6000mm B/C (31″ x 236″ Inch)

This heavy-duty horizontal lathe, with a maximum swing over bed of Ø800mm (31 inches), is a crucial machine tool in industrial environments, ideal for machining large and heavy workpieces. Renowned for its sturdy construction, this lathe features a heavily ribbed bed and large spindle bearings, ensuring stability and rigidity during demanding operations like cutting, drilling, boring, and facing. The lathe bed, typically constructed from high-quality cast iron or steel, provides a solid foundation for the workpiece and cutting tool, effectively minimizing vibrations and enhancing precision.

The spindle, supported by substantial bearings, operates at speeds ranging from 60 to 600 RPM, driven by a high-torque motor that can withstand the forces required for heavy-duty machining. The cutting tool, mounted on a cross slide, moves along the bed for precise operation and offers power feed capabilities for semi-automatic or fully automatic processes.

Additional features of this lathe include a large chuck for securely holding the workpiece, a tailstock for supporting longer pieces, and versatile tooling options such as a quick-change tool post or turret. Together, these elements and the lathe’s durable design make it a dependable choice for complex and high-stress machining tasks in manufacturing and engineering settings.
